Summary

Decode Slot Usage Plot

st-scrape ece.328 --spec-reset --settings-omit-default --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize.scrape --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize-user.scrape --plot-outliers-clip --plot c_dsu_commit c_dsu_other c_dsu_mispred_s c_dsu_rob_full_s
Decode slot usage graph.

List of Tables

  • Data Overview
  • Branch Predictor Data
  • Cache Data

    Simulated Configurations

    st-scrape ece.328 --spec-reset --settings-omit-default --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize.scrape --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize-user.scrape --uniq fSystem fbpmethod fROB fIW fmt_thread_limit fL1Line fL1A fL1_kiB fL1Lat fL2_kiB fL2A fcL2Lat fMemLat
    Fetch Mechanism
    Branch Predictor
    ROB
    Decode Width
    Threads
    Line Size
    L1 Assoc.
    L1/kiB
    L1 Latency
    L2/kiB
    L2 Assoc.
    L2 Latency
    Mem Latency
    0MBP-0 0yags 064 04 01 064 02 0128 01 08192 016 016 0300

    Simulated Benchmarks

    scpu06.gromacs-tri_st.ref scpu06.lbm-tri_st.ref scpu06.leslie3d-tri_st.ref scpu06.libquantum-tri_st.ref scpu06.mcf-tri_st.ref scpu06.milc-tri_st.ref scpu06.namd-tri_st.ref scpu06.omnetpp-tri_st.ref scpu06.povray-tri_st.ref scpu06.sjeng-tri_st.ref scpu06.zeusmp-tri_st.ref

    Data Overview

    st-scrape ece.328 --spec-reset --settings-omit-default --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize.scrape --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize-user.scrape fSerial fBenchmark fSystem fROB fIW fL1_kiB fL2_kiB dcycles cipc cbp_ratio cl1hr cl2hr
    Run ID
    Benchmark
    Fetch Mechanism
    ROB
    Decode Width
    L1/kiB
    L2/kiB
    Execution Time
    IPC
    BP Ratio
    L1 Hit Ratio
    L2 Hit Ratio
    Sort Sort Sort Sort Sort Sort Sort
    0ece.328.001 3libquantum-tri_st 0MBP-0 064 04 0128 08192 61113828776351 61.586 70.9743 90.9982 20.3274
    1ece.328.002 4mcf-tri_st 0MBP-0 064 04 0128 08192 1594130962801 10.682 20.9298 00.8179 70.9073
    2ece.328.003 7omnetpp-tri_st 0MBP-0 064 04 0128 08192 51075694915062 00.518 60.9721 10.9174 40.6103
    3ece.328.004 9sjeng-tri_st 0MBP-0 064 04 0128 08192 91825283303891 71.658 40.9553 70.9978 30.3789
    4ece.328.006 0gromacs-tri_st 0MBP-0 064 04 0128 08192 3983796946445 81.732 10.9284 20.9808 90.9998
    5ece.328.007 1lbm-tri_st 0MBP-0 064 04 0128 08192 41026903126473 41.122 100.9956 100.9997 00.0356
    6ece.328.008 2leslie3d-tri_st 0MBP-0 064 04 0128 08192 101934385235041 20.806 80.9772 30.9891 60.8531
    7ece.328.009 5milc-tri_st 0MBP-0 064 04 0128 08192 2754375210122 31.071 00.9176 60.9932 10.0399
    8ece.328.010 6namd-tri_st 0MBP-0 064 04 0128 08192 71400467919082 91.760 30.9514 80.9979 80.9680
    9ece.328.011 8povray-tri_st 0MBP-0 064 04 0128 08192 0520827435923 101.919 50.9667 50.9908 101.0000
    10ece.328.014 10zeusmp-tri_st 0MBP-0 064 04 0128 08192 81522406309089 51.140 90.9912 40.9894 50.7298

    Branch Predictor Data

    st-scrape ece.328 --spec-reset --settings-omit-default --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize.scrape --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize-user.scrape fSerial fBenchmark fbpmethod fbphistory cbp_ratio cbp_bad_ratio cbp_bad_rate dttrbpc cbp_bad_impact
    Run ID
    Benchmark
    Branch Predictor
    BP History Length
    BP Ratio
    BP Bad Ratio
    BP Bad / M Insn
    Time to Resolve Mispred. Branch
    BP Bad Impact
    Sort Sort Sort Sort Sort Sort Sort
    0ece.328.001 3libquantum-tri_st 0yags 016 70.9743 30.0257 95674 520.6 80.4675
    1ece.328.002 4mcf-tri_st 0yags 016 20.9298 80.0702 1011106 934.6 101.5371
    2ece.328.003 7omnetpp-tri_st 0yags 016 60.9721 40.0279 74641 834.0 90.6312
    3ece.328.004 9sjeng-tri_st 0yags 016 40.9553 60.0447 85626 317.7 70.3983
    4ece.328.006 0gromacs-tri_st 0yags 016 10.9284 90.0716 41924 418.3 40.1408
    5ece.328.007 1lbm-tri_st 0yags 016 100.9956 00.0044 044 216.0 00.0028
    6ece.328.008 2leslie3d-tri_st 0yags 016 80.9772 20.0228 2449 09.5 20.0171
    7ece.328.009 5milc-tri_st 0yags 016 00.9176 100.0824 52556 723.6 50.2413
    8ece.328.010 6namd-tri_st 0yags 016 30.9514 70.0486 31557 621.9 30.1364
    9ece.328.011 8povray-tri_st 0yags 016 50.9667 50.0333 63183 520.6 60.2623
    10ece.328.014 10zeusmp-tri_st 0yags 016 90.9912 10.0088 1198 110.2 10.0081

    Cache Data

    st-scrape ece.328 --spec-reset --settings-omit-default --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize.scrape --settings /share/petalMD3K/sverma3/rundata/batch.ece.0328/settings-htmlize-user.scrape fSerial fBenchmark cncpi c_load_nc_l2_impact c_load_nc_local_impact c_load c_load_nc c_load_per_insn c_load_nc_per_insn c_load_nc_by_per_nc c_load_nc_l1_per_nc c_load_nc_l2_per_nc c_load_nc_local_per_nc
    Run ID
    Benchmark
    NCPI
    NC L2 Impact
    NC Mem Impact
    Loads
    NC Loads
    Loads / Insn
    NC Loads / Insn
    NC LSQ / NC Load
    NC L1 / NC Load
    NC L2 / NC Load
    NC Mem / NC Load
    Sort Sort Sort Sort Sort Sort Sort Sort Sort Sort Sort Sort Sort
    0ece.328.001 3libquantum-tri_st 42.522 20.003 40.119 4218306042381 4136912241344 00.1236 00.0775 30.0216 80.9766 20.0006 40.0012
    1ece.328.002 4mcf-tri_st 95.868 102.409 94.863 0100449557434 093369473340 90.2480 90.2305 20.0117 00.8083 100.1633 90.0167
    2ece.328.003 7omnetpp-tri_st 107.718 90.592 107.471 1114399848629 1105886481357 50.2052 50.1899 50.0337 30.8864 90.0487 100.0311
    3ece.328.004 9sjeng-tri_st 32.413 30.009 50.283 10521247312584 10520888075151 30.1722 30.1721 70.0423 50.9556 30.0008 50.0013
    4ece.328.006 0gromacs-tri_st 22.310 80.249 10.001 8402714506450 8387618989240 70.2364 80.2275 90.1089 20.8740 80.0171 10.0000
    5ece.328.007 1lbm-tri_st 63.566 00.000 30.040 3172193683988 3132428642877 10.1495 10.1150 40.0263 70.9734 00.0000 30.0003
    6ece.328.008 2leslie3d-tri_st 84.964 70.134 60.455 7390302362631 7350412895558 100.2504 70.2248 00.0034 100.9857 70.0093 60.0016
    7ece.328.009 5milc-tri_st 73.734 10.002 81.044 2128816355241 2124195645817 20.1594 20.1537 100.1748 10.8196 10.0002 80.0054
    8ece.328.010 6namd-tri_st 12.273 40.027 20.017 9519121024521 9511667182984 60.2106 60.2076 60.0363 60.9617 40.0020 20.0001
    9ece.328.011 8povray-tri_st 02.084 60.129 00.000 5243021138734 5239780165485 80.2431 100.2399 80.0878 40.9038 60.0084 00.0000
    10ece.328.014 10zeusmp-tri_st 53.508 50.091 70.665 6326728389879 6319159582805 40.1882 40.1838 10.0044 90.9851 50.0077 70.0029
